LBW6GL-M1T14VW
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
LBW FLUSH ILLD PB MOME. WHITE
PDF
/
Inventory: 4228
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Panel Mount, Front
Technical
Operating Temperature -25°C~55°C
Packaging Bulk
Series LBW
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Standard, Illuminated
Voltage - Rated DC 30V
Current Rating (Amps) 100mA AC/DC
Ingress Protection IP65 - Dust Tight, Water Resistant
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Round, Button, Full Guard
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 22.30mm Dia
Color - Actuator/Cap White
Illumination Voltage (Nominal) 24VAC/DC
Illumination Type, Color LED, White
Electrical Life 50,000 Cycles
Mechanical Life 2,000,000 Cycles
Compliance
RoHS Status ROHS3 Compliant
