46-01-07-500-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Switch Push Button N.O./N.C. SPDT Plunger 0.25A 220VAC Alternate Contact Panel Mount
PDF
/
Buying Options
Total Price: USD $32.84
Unit Price: USD $32.843506
≥1 USD $32.843506
≥200 USD $12.710185
≥500 USD $12.263799
≥1000 USD $12.043232
Inventory: 5151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Front, Panel, Through Hole
Mounting Type Panel Mount, Front
Housing Material Phenolic
Actuator Material BRASS
Center Contact Material SILVER
Terminal Material SILVER
End Contact Material SILVER
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2007
Series 46
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Turret
ECCN Code EAR99
Type Standard
Terminal Finish Tin/Silver (Sn/Ag)
Additional Feature WIPING CONTACT
HTS Code 8536.50.70.00
Current Rating (Amps) 250mA AC
Current Rating 250mA
Termination Style Solder Lug
Voltage - Rated AC 115V
Body Length or Diameter 14.99mm
Body Breadth 14.99 mm
Actuator Type Square, Button
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Square - 15.49mm2
Contact Resistance 0.025mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap White
Sealing EPOXY TERMINAL SEALED
Max Voltage Rating (AC) 220V
Max Current Rating 250mA
Dielectric Withstanding Voltage 1000VAC V
Electrical Life 250,000 Cycles
Contact Current(AC)-Max 0.25A
Contact (AC) Max Rating R Load .25A@115VAC
Contact Function (ON)-OFF
Dimensions
Body Height 35.92mm
Length - Termination 0.22 inch
Actuator Length 0.255 inch
Compliance
RoHS Status RoHS Compliant
