30-01-01-500-04

Grayhill Inc.
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description Switch Push Button N.O. SPST Square Button 1A 220VAC Momentary Contact Panel Mount
PDF
/
Inventory: 2008
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Front, Panel
Mounting Type Panel Mount, Front
Housing Material Phenolic

Technical

Operating Temperature -40°C~85°C
Packaging Bulk
Published 2007
Series 30
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard
Terminal Finish Silver (Ag)
HTS Code 8536.50.70.00
Current Rating (Amps) 1A AC
Orientation Straight
Depth 14.99mm
Current Rating 1A
Termination Style Solder Lug
Voltage - Rated AC 115V
Actuator Type Square, Button
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Square - 15.49mm2
Color - Actuator/Cap Green
Sealing EPOXY TERMINAL SEALED
Max Voltage Rating (AC) 220V
Max Current Rating 1A
Electrical Life 1,000,000 Cycles
Throw Configuration SPST
Contact Current(AC)-Max 1A
Contact (AC) Max Rating R Load 1A@115VAC
Operating Force-Max 3.89 N

Dimensions

Length 14.99mm
Body Height 22.35mm
Actuator Length 6.48mm

Compliance

RoHS Status RoHS Compliant
