LP11OA1TASRB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches SPST-NO Off-Mom LED, Red/Blue
PDF
/
Buying Options
Total Price: USD $7.48
Unit Price: USD $7.482822
≥1 USD $7.482822
≥10 USD $7.059266
≥100 USD $6.659688
≥500 USD $6.282721
≥1000 USD $5.927101
Inventory: 1193
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.453 inch
Length - Termination 0.142 inch
Body Height 11.5062mm
Technical
Actuator Travel 4.4958 mm
Contact Function OFF-(ON)
PCB Hole Count 9
Contact (DC) Max Rating R Load 0.1A@12VDC
Hole Diameter 8.2 mm
Illumination Color Blue, Red
Illumination Type LED
Mechanical Life 1,000,000 Cycles
Throw Configuration SPST
Electrical Life 1,000,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Illumination Type, Color LED, Red/Blue
Illumination Voltage (Nominal) 2.2 3.5VDC
Contact Current(DC)-Max 0.1A
Color - Actuator/Cap Clear
Insulation Resistance 100000000Ohm
Contact Resistance 0.2mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Square, Button
Body Breadth 15.0114 mm
Body Length or Diameter 15.0114mm
Termination Style PC Pin
Current Rating 100mA
Current Rating (Amps) 100mA DC
Voltage - Rated DC 12V
Terminal Finish Gold (Au)
Type Standard, Illuminated
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
JESD-609 Code e4
Series LP11
Published 2008
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
