112-PM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches ON(ON) METL WIRE/LDS
PDF
/
Inventory: 7143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.437 inch
Length - Termination 0.293 inch
Body Height 13.76mm
Technical
Operating Force-Max 35.59 N
Body Color BLACK
Bushing Length 0.562 inch
Contact Function ON-(ON)
Contact (DC) Max Rating R Load 3A@125VDC
Hole Diameter 12.7 mm
Contact (AC) Max Rating R Load 3A@125VAC
Contact Current(AC)-Max 3A
Contact Current Rating 3A
Mechanical Life 100,000 Cycles
Throw Configuration SP, SPDT
Electrical Life 25,000 Cycles
Dielectric Withstanding Voltage 1000VAC V
Contact Current(DC)-Max 3A
Color - Actuator/Cap Silver
Insulation Resistance 100000000Ohm
Panel Cutout Dimensions Circular - 12.70mm Dia
Switch Function On-Mom
Circuit SPDT
Actuator Type Round, Button
Body Breadth 13.31 mm
Body Length or Diameter 30.04mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 3A
Current Rating (Amps) 3A AC
HTS Code 8536.50.90.31
Type Standard
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 110
Published 2012
Packaging Bulk
Operating Temperature 0°C~85°C
Physical
Actuator Material BRASS
Housing Material Resin
Mounting Type Panel Mount, Rear
Mount Panel
Contact Plating Nickel
Supply Chain
Factory Lead Time 6 Weeks
