TP11LTV3LE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches Pushbutton
PDF
/
Inventory: 8767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 5.46mm
Length 10.57mm
Technical
Max Voltage Rating (DC) 28V
Throw Configuration SPST
Electrical Life 60,000 Cycles
Max Current Rating 1A
Max Voltage Rating (AC) 120V
Color - Actuator/Cap Black
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round, Plunger
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 1A
Depth 7.11mm
Orientation Straight
Current Rating (Amps) 1A AC/DC
Voltage - Rated DC 28V
Type Standard
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series TP
Published 2006
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Polyester, Thermoplastic
Housing Material Stainless Steel
Mounting Type Panel Mount, Rear
Mount Brackets, Panel
Contact Plating Gold
Contact Material Silver
Supply Chain
Factory Lead Time 12 Weeks
