AP4C207TZBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Switch Push Button N.O. SPST Concave Button 0.4A 125VAC 50VDC Momentary Contact Solder Lug Panel Mount
PDF
/
Inventory: 9217
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Ingress Protection IP67 - Dust Tight, Waterproof
Depth 17.4mm
Current Rating 200mA
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Round, Button
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 13.80mm Dia
Contact Resistance 50mOhm
Color - Actuator/Cap Black
Illumination Voltage (Nominal) 3.8VDC
Illumination Type, Color LED, Blue
Max Voltage Rating (AC) 125V
Max Current Rating 400mA
Electrical Life 1,000,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 50V
Mechanical Life 1,000,000 Cycles
Illumination Type LED
Thread Size M13
Illumination Color Blue
Orientation Straight
Current Rating (Amps) 125mA AC 200mA DC
Voltage - Rated DC 24V
Type Standard, Illuminated
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AP
Published 2012
Packaging Bulk
Operating Temperature -40°C~85°C
Dimensions
Length 17.4mm
Actuator Length 3.99mm
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
Physical
Actuator Material Polybutylene
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Gold, Silver
Supply Chain
Factory Lead Time 14 Weeks
