8161S1H9AQE2

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description Switch Push Button ON ON SPDT Round Plunger 6A 250VAC 28VDC Alternate Contact PC Pins Thru-Hole
PDF
/
Buying Options
Total Price: USD $16.81
Unit Price: USD $16.806433
≥1 USD $16.806433
Inventory: 7294
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Contact Material Silver
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Stainless Steel
Actuator Material Glass, Nylon, Polyester

Technical

Operating Temperature -30°C~65°C
Packaging Bulk
Published 2012
Series 8060
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Type Standard
Max Operating Temperature 65°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Orientation Right Angle
Depth 36.575mm
Current Rating 6A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Round, Button
Circuit SPDT
Switch Function On-On
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Electrical Life 50,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 28V

Dimensions

Length 12.57mm
Actuator Length 8.1mm

Compliance

RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
