BX2506JT image
Favorite
BX2506JT image
Favorite
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description Audio Transformers / Signal Transformers SMD ADSL Line Xfmr 1200uH 3Ohms
PDF
/
Inventory: 6357
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount

Technical

Published 2003
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO, TURNS RATIO: 2.29 : 1, COMPATIBLE WITH EAGLE II CPE CHIPSET
Packing Method TAPE & REEL
Shielding Unshielded
Physical Dimension L9.53XB9.2XH12.0 (mm)
DC Resistance (DCR) 3Ohm
Isolation Voltage 1.5kV
Transformer Type TELECOM TRANSFORMER
Turns Ratio - Primary:Secondary 2.29:1

Dimensions

Height 12mm
Length 9.2mm
Width 9.53mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
