RoHS
/
Package DIP
Category Transformers / Pulse Transformers
Description
Pulse Transformers Pulse 1.2ct:1ct8.8mH340Vus
PDF
/
Buying Options
Total Price: USD $8.84
Unit Price: USD $8.83734
≥1 USD $8.83734
≥10 USD $8.33711
≥100 USD $7.8652
≥500 USD $7.42
≥1000 USD $7
≥3000 USD $6.60377
Inventory: 6702
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 15.06mm
Length 15.06mm
Height Seated (Max) 0.640 16.26mm
Height 15.75mm
Technical
ET Product-Min 340 V-us
ET (Volt-Time) 340VμS
Turns Ratio - Primary:Secondary 1.2:1
Transformer Type PULSE TRANSFORMER
Isolation Voltage 2000V
Application GENERAL PURPOSE
Lead/Base Style PC Pin
DC Resistance (DCR) 2.5Ohm
Inductance 8.8mH
Physical Dimension L15.06XB15.06XH15.75 (mm)
Approval Agency UL
Number of Functions 1
Packing Method TUBE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.593Lx0.593W 15.06mmx15.06mm
Series 1000
Packaging Bulk
Operating Temperature -40°C~130°C
Physical
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
