PE-65812FNLT image
Favorite
PE-65812FNLT image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Specialty Transformers
Description XFRMR DIGITAL AUDIO 1:1 2.5MH
PDF
/
Buying Options
Total Price: USD $5.01
Unit Price: USD $5.0072
≥1 USD $5.0072
≥10 USD $4.0568
≥100 USD $3.279584
≥500 USD $3.072608
≥1000 USD $2.934448
Inventory: 137
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 12.07mm
Length 14.37mm
Height Seated (Max) 0.340 8.64mm

Technical

Number of Primary Winding 1
Number of Secondary Winding 1
Turns Ratio - Primary:Secondary 1:1
Transformer Type DATACOM TRANSFORMER
Isolation Voltage 2kV
Insertion Loss 3 dB
Application SIGNAL
Lead/Base Style Gull Wing
Inductance 2.5mH
Approval Agency UL
Depth 15.24mm
Subcategory Other Transformers
Min Operating Temperature 0°C
Max Operating Temperature 70°C
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.500Lx0.566W 12.70mmx14.37mm
Published 2013
Packaging Tape & Reel (TR)

Physical

Core Material Plastic
Number of Pins 8
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
