RXEF250
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 72V 2.5A RADIAL
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.60016
≥100 USD $0.5808
≥500 USD $0.488752
≥1000 USD $0.405768
≥3000 USD $0.368861
Inventory: 1142
Minimum: 1
-
+
Technical Details
Physical
Terminal Shape WIRE
Surface Mount NO
Package / Case Radial, Disc
Mounting Type Through Hole
Technical
Operating Temperature -40°C~85°C
Packaging Bag
Published 2005
Series PolySwitch?, RXEF
Size / Dimension 0.819Dia x 0.118 T 20.80mmx3.00mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Type Polymeric
Resistance 130mOhm
Terminal Finish Matte Tin (Sn)
Additional Feature 0.05-0.08 OHMS AT 20 DEG CEL
Packing Method BULK
Approval Agency CQC, CSA, TUV, UL
Operating Supply Voltage 72V
Lead Spacing 0.400 10.15mm
Current - Max 40A
Hold Current 2.5A
Thermistor Application TEMPERATURE SENSING
Voltage - Max 72V
Time to Trip 15.6s
Resistance - Initial (Ri) (Min) 50mOhm
Resistance - Post Trip (R1) (Max) 130mOhm
Trip Current 5A
Dimensions
Height Seated (Max) 1.000 25.40mm
Compliance
RoHS Status ROHS3 Compliant
Supply Chain
Factory Lead Time 10 Weeks
