SDP0720Q38CB
RoHS
RoHS compliant
RoHS compliantPackage 8-LDFN
Category Circuit Protection / TVS - Mixed Technology
Description
SIDACTOR BI 72V 500A QFN 5X6 8L
PDF
/
Buying Options
Total Price: USD $109.89
Unit Price: USD $109.8884
≥1 USD $109.8884
≥10 USD $106.34395
≥100 USD $102.79855
≥500 USD $92.16425
Inventory: 549
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-LDFN
Surface Mount YES
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
Published 2009
Series SIDACtor?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Ethernet
Additional Feature UL RECOGNIZED
Subcategory Silicon Surge Protectors
Technology Mixed Technology
Terminal Position BOTTOM
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
Qualification Status Not Qualified
Number of Elements 1
Working Voltage 8V
Configuration SINGLE
Number of Circuits 2
Hold Current 150mA
Non-Repetitive Pk On-state Cur 30 A
Voltage - Clamping 65V
Compliance
RoHS Status ROHS3 Compliant
