DPC-20-220 image
Favorite
DPC-20-220 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 4.4VA THRU HOLE
PDF
/
Inventory: 5529
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 18 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.313lb 141.97g

Technical

Published 1997
Series DPC
Size / Dimension 41.30mm Lx31.80mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Max Power Dissipation 4.4W
Frequency 500Hz
Termination Style PC Pin
Approval Agency UL; CSA
Number of Contacts 8
Voltage - Isolation 1500Vrms
Max Output Current 220mA
Current - Output (Max) Parallel 440mA Series 220mA
Output Power 4.4W
Power - Max 4.4VA
Output Voltage 1 10V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Output Voltage 2 10V
Number of Secondary Winding 2
VA Rating 4.4 VA

Dimensions

Height 34.9mm
Height Seated (Max) 34.92mm
Length 41.3mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
