PA1005.040QNLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
XFMR CURR SENSE 1:40 AECQ SMD
PDF
/
Buying Options
Total Price: USD $1.9
Unit Price: USD $1.9008
≥1 USD $1.9008
≥10 USD $1.52328
≥100 USD $1.237632
≥500 USD $1.205776
≥1000 USD $1.174008
≥3000 USD $1.142275
Inventory: 1129
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.217 5.50mm
Technical
Turns Ratio - Primary:Secondary 1:40
Input Current 20A
Frequency Range 20kHz~1MHz
DC Resistance (DCR) 0.75mOhm Primary 1.14Ohm Secondary Max
Inductance 320μH
Termination Style Gull Wing
Frequency 1MHz
Type Invasive
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.284Lx0.330W 7.21mmx8.38mm
Series PA1005QNL
Packaging Tape & Reel (TR)
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
