ST6-20B16 image
Favorite
ST6-20B16 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 2770
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 47.244mm
Length 57.15mm
Height 36.58mm

Technical

VA Rating 20 VA
Secondary Winding(s) Dual
Output Voltage 2 10V
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 10V
Power - Max 20VA
Current - Output (Max) Parallel 2A Series 1A
Max Output Current 1A
Voltage - Isolation 2500Vrms
Physical Dimension 57.15mm X 47.244mm X 36.576mm
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 20W
Power Rating 20W
HTS Code 8504.31.40.35
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 57.15mm Lx47.24mm W
Series Split Bobbin Plug-In
Published 2009
Packaging Bulk

Physical

Weight 0.8lb 362.87g
Mounting Type Through Hole
Mount Through Hole
