DPC-40-110B26
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 4.4VA THRU HOLE
PDF
/
Inventory: 2421
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 31.75mm
Length 41.27mm
Height Seated (Max) 34.93mm
Height 1.375mm
Technical
VA Rating 4.4 VA
Number of Secondary Winding 2
Output Voltage 2 20V
Voltage - Secondary (Full Load) Parallel 20V Series 40V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 20V
Power - Max 4.4VA
Current - Output (Max) Parallel 220mA Series 110mA
Max Output Current 110mA
Voltage - Isolation 1500Vrms
Physical Dimension L41.27XB31.75XH34.92 (mm)
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 4.4W
Power Rating 4.4W
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.28mm Lx31.75mm W
Series PC Plug-In
Published 2009
Physical
Weight 0.313lb 141.97g
Mounting Type Through Hole
Mount Through Hole
