PL1961NL

PulseR
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Current Sense Transformers
Description XFM CST-37 CURR SENSE 1:1: PBC
PDF
/
Inventory: 7295
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Seated (Max) 0.280 7.11mm

Technical

Turns Ratio - Primary:Secondary 1:1:200
DC Resistance (DCR) 2.3mOhm Primary Max 4.2Ohm Secondary Max
Inductance 59.2mH
Termination Style J Lead
Current Rating (Amps) 15A
Type Invasive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.495Lx0.490W 12.57mmx12.45mm

Physical

Mounting Type Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
