Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 10VA THRU HOLE
PDF
/
Inventory: 9845
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.133lb 60.33g

Technical

Size / Dimension 60.00mm Lx42.50mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Laminated Core
Max Power Dissipation 10W
Termination Style PC Pin
Max Output Current 333mA
Current - Output (Max) Parallel 666mA Series 333mA
Power - Max 10VA
Voltage - Primary 230V
Primary Winding(s) Single
Center Tap No
Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 15V Series 30V

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 42.5mm
Length 60mm
Height Seated (Max) 34.60mm
Height 1.36mm
