PL2035T

PulseR
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description XFMR CURRENT SENSE 1:50 T& PBC
PDF
/
Inventory: 992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mounting Type Surface Mount

Technical

Packaging Tape & Reel (TR)
Size / Dimension 0.330Lx0.284W 8.38mmx7.21mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Invasive
Current Rating (Amps) 20A
Termination Style Gull Wing
Inductance 500μH
DC Resistance (DCR) 0.75mOhm Primary Max 1.5Ohm Secondary Max
Frequency Range 50kHz~1MHz
Turns Ratio - Primary:Secondary 1:50

Dimensions

Height Seated (Max) 0.217 5.50mm

Compliance

RoHS Status Non-RoHS Compliant
