165V22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
BOBBINS TRANSFORMER - More Details
PDF
/
Buying Options
Total Price: USD $106.14
Unit Price: USD $106.1368
≥1 USD $106.1368
≥10 USD $102.59832
Inventory: 25
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 95.25mm
Technical
Number of Secondary Winding 1
Voltage - Secondary (Full Load) 22V
Center Tap Yes
Primary Winding(s) Single
Voltage - Primary 115V
Input Current 20A
Power - Max 440VA
Output Current 20A
Max Output Current 20A
Voltage - Isolation 2000Vrms
Approval Agency UL; CSA
Termination Style Wire Leads
Current Rating 20A
Max Power Dissipation 440W
Power Rating 440W
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 114.30mm Lx114.30mm W
Series 165
Published 2000
Physical
Weight 14lbs 6.4kg
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 4 Weeks
