1182U30
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
TRANSFORMER TOROIDAL POWER
PDF
/
Buying Options
Total Price: USD $162.01
Unit Price: USD $162.008
≥1 USD $162.008
≥10 USD $150.43864
≥100 USD $144.652288
Inventory: 31
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 73.15mm
Height 73.152mm
Technical
Secondary Current 16.7A
VA Rating 1000 VA
Number of Secondary Winding 2
Output Voltage 2 30V
Voltage - Secondary (Full Load) Parallel 30V Series 60V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 117V
Outside Diameter 158.75 mm
Output Voltage 1 30V
Power - Max 1000VA
Current - Output (Max) Parallel 33.4A Series 16.7A
Voltage - Isolation 4000Vrms
Physical Dimension D158.75XH76.2 (mm)
Termination Style Wire Leads
Frequency 60Hz
Power Rating 1kW
HTS Code 8504.31.60.00
Type Toroidal
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 158.75mm Dia
Series 1182
Published 2014
Physical
Weight 17lbs 7.7kg
Surface Mount NO
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 4 Weeks
