PH9363NLT image
Favorite
PH9363NLT image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Switching Converter, SMPS Transformers
Description XFRMER FLYBACK DC/DC CONV SMD
PDF
/
Buying Options
Total Price: USD $4.54
Unit Price: USD $4.5408
≥1 USD $4.5408
≥10 USD $3.68104
≥100 USD $2.97616
≥500 USD $2.788368
≥1000 USD $2.662968
≥3000 USD $2.584666
Inventory: 659
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Seated (Max) 0.266 6.75mm

Technical

Intended Chipset ACPL-32JT, ACPL-302J
Footprint 0.472 L x 0.512 W (12.00mm x 13.00mm)
Voltage - Primary 8V~18V
Voltage - Isolation 2500Vrms
Frequency 80kHz
Applications Flyback Converters
Type For DC/DC Converters
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.472Lx0.366W 12.00mmx9.30mm
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Mounting Type Surface Mount

Supply Chain

Factory Lead Time 9 Weeks
