RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 120/250VAC 6A CHAS
PDF
/
Buying Options
Total Price: USD $25.12
Unit Price: USD $25.124
≥1 USD $25.124
≥10 USD $24.31733
≥100 USD $20.264605
Inventory: 36
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 52.8mm
Length 98mm
Technical
Frequency - Operating 50/60Hz
Filter Type Single Phase
Current 6A
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Leakage Current 400μA
ELV Compliant
Inductance 1.8mH
Configuration Two Stage
Approval Agency CSA, UR, VDE
Voltage - Rated AC 120V 250V
Termination Style Quick Connect
Frequency 5.06kHz
Current Rating 6A
Depth 38.9mm
Voltage - Rated DC 250V
Capacitance 543nF
Voltage - Rated 250V
Applications General Purpose
Min Operating Temperature -10°C
Max Operating Temperature 40°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series S
Published 2004
Packaging Bulk
Operating Temperature -10°C~40°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Flanges, Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 19 Weeks
