FN2020-16-07

Schaffner EMC Inc.
RoHS
RoHS RoHS compliant
Package /
Category Filters / Power Line Filter Modules
Description Power Line Filters GENERAL EMI 16A FILTER 1-PHASE
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Chassis, Chassis Mount
Mounting Type Chassis Mount

Technical

Operating Temperature -25°C~100°C
Packaging Tray
Published 2009
Series FN 2020
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire
Applications General Purpose
Additional Feature INDUCTANCE 0.65 MILLIHENRY
Depth 46.6mm
Current Rating 16A
Frequency 400Hz
Termination Style Wire Leads
Voltage - Rated AC 250V
Approval Agency CSA, ENEC, UR
Physical Dimension L50.5XB44.5XH29.3 (mm)/L1.988XB1.752XH1.154 (inch)
Configuration Single Stage
Inductance 650μH
Leakage Current 740μA
Max Voltage Rating (AC) 250V
Max Current Rating 16A
Filter Type Single Phase
Frequency - Operating DC~400Hz
High Pot 2000 V

Dimensions

Height 29.3mm
Length 46.6mm
Width 44.5mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
