SC-20-100
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, No Base, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes 20amp 1mH
PDF
/
Buying Options
Total Price: USD $13.48
Unit Price: USD $13.4816
≥1 USD $13.4816
≥10 USD $8.88727
≥100 USD $8.64211
≥500 USD $8.274376
Inventory: 62
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.181 30.00mm
Technical
Inductance @ Frequency 1mH @ 100kHz
Current Rating (Max) 20A
DC Resistance (DCR) (Max) 8mOhm
Number of Lines 2
Filter Type Power Line
Inductor Type GENERAL PURPOSE INDUCTOR
Inductance 1 mH
Voltage - Rated DC 250V
HTS Code 8504.50.80.00
Resistance 8mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 2.362Dia 60.00mm
Series SC
Published 2000
Packaging Bulk
Operating Temperature -25°C~105°C
Physical
Package / Case Horizontal, No Base, 4 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 27 Weeks
