62-PQF-030-5-12

API Technologies Corp
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description Power Line Filter Single Stage 50Hz/60Hz 3A 250VAC Quick Connect Flange Mount
PDF
/
Inventory: 10015
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Chassis Mount
Mounting Type Chassis Mount

Technical

Operating Temperature -25°C~85°C
Packaging Tray
Series 62-PQF
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Applications General Purpose
Additional Feature INDUCTANCE 8 MILLI HENRY
Capacitance 3.3nF
Depth 51mm
Termination Style Quick Connect
Voltage - Rated AC 250V
Approval Agency CSA, TUV, UR
Physical Dimension L49.5XB32.0XH23.0 (mm)/L1.949XB1.26XH0.906 (inch)
Configuration Single Stage
Inductance 8mH
Max Voltage Rating (AC) 250V
Max Current Rating 3A
Filter Type Single Phase
Rated Current 3A
Leakage Current (Max) 0.5mA
Frequency - Operating 50/60Hz
Insulation Resistance-Min 300MOhm
High Pot 1500 V

Dimensions

Height 23mm
Length 67.5mm
Width 32mm

Compliance

RoHS Status RoHS Compliant
