RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description Switch On-Off P Corcom RoHS Compliant 2012 Power Entry Connector Receptacle, Male Blades - Module 6A 120VAC 0.031-0.114 0.79mm-2.90mm
PDF
/
Inventory: 9378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 25 Weeks

Physical

Mounting Type Panel Mount, Snap-In

Technical

Packaging Bulk
Published 2012
Series P, Corcom
Feature Conversion Clip, Voltage Selector
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect - 0.187 (4.7mm)
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Approval Agency CSA, UL, VDE
Panel Cutout Dimensions Variable Size
Connector Style IEC 320-C14
Voltage - UL 250VAC
Current - UL 6A
Voltage - IEC 120VAC
Filter Type Filtered (EMI, RFI) - Commercial
Current - IEC 6A
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Fuse Holder
Switch Features Switch On-Off

Dimensions

Panel Thickness 0.031 ~ 0.114 0.79mm ~ 2.90mm

Compliance

RoHS Status RoHS Compliant
