10EH4C image
Favorite
RoHS
RoHS RoHS compliant
Package 125
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description FILTER RFI PWR LINE MED .250 10A
PDF
/
Buying Options
Total Price: USD $13.3
Unit Price: USD $13.2968
≥1 USD $13.2968
≥10 USD $12.65
Inventory: 202
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mount Chassis Mount, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case 125

Technical

Packaging Bulk
Published 2008
Series H, Corcom
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
Connector Type Receptacle, Male Blades
Resistance 6GOhm
Number of Positions 3
Max Operating Temperature 40°C
Min Operating Temperature -10°C
Gender Male
Voltage - Rated 250V
Capacitance 10nF
Voltage - Rated DC 250V
Current Rating 10A
Frequency 5.06kHz
Voltage - Rated AC 250V
Approval Agency CSA, UL, VDE
Panel Cutout Dimensions Rectangular - 30.48mm x 20.83mm
Inductance 360 μH
ELV Compliant
Leakage Current 2μA
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Connector Style IEC 320-C14
Current 10A
Number of Poles 3
Voltage - UL 250VAC
Current - UL 10A
Voltage - IEC 120/250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Current - IEC 10A
Accomodates a Fuse No
Fuse No

Dimensions

Length 50.3mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
