EBQA-04-D-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Header
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
≥10 USD $0.37752
≥100 USD $0.322784
≥500 USD $0.290048
≥1000 USD $0.284064
≥3000 USD $0.241762
Inventory: 46
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series EB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 4
Color Green
Pitch 0.200 5.08mm
Insulation Height 0.335 8.51mm
Termination Style Solder
Contact Tail Length 0.157 4.00mm
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 15A
Header Orientation 90°, Right Angle
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
