PX0695/15/28
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT IEC320-2-2F PNL QC
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6752
≥1 USD $2.6752
≥10 USD $2.42528
≥100 USD $2.297152
≥500 USD $2.243648
≥1000 USD $2.136816
≥3000 USD $1.881
Inventory: 227
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.059 1.50mm
Technical
Accomodates a Fuse No
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current - UL 15A
Connector Style IEC 320-2-2/F
Panel Cutout Dimensions Rectangular - 32.26mm x 24.77mm
Approval Agency CSA, ENEC, UL, VDE
Current Rating 10A
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Voltage - Rated DC 250V
Additional Feature STANDARDS: CSA, UL, VDE
Number of Positions 3
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PX
Published 2011
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type Panel Mount, Snap-In
Contact Plating Tin
Contact Material BRASS
Supply Chain
Factory Lead Time 24 Weeks
