STGIB8CH60TS-L
RoHS
RoHS compliant
RoHS compliantPackage 26-PowerDIP Module (1.146, 29.10mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
SLLIMM
PDF
/
Buying Options
Total Price: USD $24.16
Unit Price: USD $24.16325
≥1 USD $24.16325
≥10 USD $19.8265
≥100 USD $19.2071
≥500 USD $18.5877
≥1000 USD $17.96735
Inventory: 569
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current 12A
Voltage 600V
Configuration 3 Phase Inverter
Temperature Grade AUTOMOTIVE
Voltage - Isolation 1500Vrms
Operating Temperature (Min) -40°C
Operating Temperature (Max) 125°C
JESD-30 Code R-XDFM-T26
Base Part Number STGIB8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Additional Feature ALSO REQUIRE 13V TO 18V; 0V TO 400V SUPPLY
Type IGBT
Number of Terminations 26
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SLLIMM?
Physical
Surface Mount NO
Package / Case 26-PowerDIP Module (1.146, 29.10mm)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 26 Weeks
