PM150CSD120

Powerex Inc.
RoHS
RoHS RoHS compliant
Package Power Module
Category Discrete Semiconductor Products / Power Driver Modules
Description MOD IPM 6PAC 1200V 150A
PDF
/
Inventory: 3712
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Current 150A
Voltage 1.2kV
Configuration 3 Phase
Voltage - Isolation 2500VDC
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X19
Reach Compliance Code unknown
Supply Voltage 15V
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology HYBRID
HTS Code 8542.39.00.01
Type IGBT
ECCN Code EAR99
Number of Terminations 19
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Intellimod?
Published 2000

Physical

Surface Mount NO
Package / Case Power Module
Mounting Type Chassis Mount
