FSBB30CH60DF
RoHS
RoHS compliant
RoHS compliantPackage 27-PowerDIP Module (1.205, 30.60mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
MODULE SPM 600V 30A SPMPA
PDF
/
Buying Options
Total Price: USD $11.47
Unit Price: USD $11.474746
≥1 USD $11.474746
≥10 USD $11.009979
≥30 USD $10.203859
≥100 USD $9.501457
Inventory: 1600
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Min Breakdown Voltage 600V
Collector Emitter Voltage (VCEO) 2.1V
Max Current Rating 30A
Configuration 3 Phase Inverter
Voltage - Isolation 2500Vrms
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
HTS Code 8541.29.00.95
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
Type IGBT
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Series Motion SPM? 3
Published 2016
Physical
Weight 21.978g
Package / Case 27-PowerDIP Module (1.205, 30.60mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE, NOT REC (Last Updated: 2 days ago)
Factory Lead Time 14 Weeks
