FSB50250US
RoHS
/
Package Module
Category Discrete Semiconductor Products / Power Driver Modules
Description
Motor / Motion / Ignition Controllers & Drivers 500V, 0.5A
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $3.996802
≥1 USD $3.996802
≥10 USD $3.597123
≥100 USD $3.370638
Inventory: 478
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 36 Weeks
Lifecycle Status ACTIVE, NOT REC (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Package / Case Module
Number of Pins 23
Weight 5.142g
Technical
Published 2014
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 23
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8541.29.00.95
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 15V
Time@Peak Reflow Temperature-Max (s) 30
Operating Supply Voltage 400V
Voltage 500V
Analog IC - Other Type AC MOTOR CONTROLLER
Power Dissipation-Max 13W
Nominal Supply Current 200μA
Current 1.1A
Voltage - Breakdown (Min) 500V
Collector Emitter Voltage (VCEO) 500V
Max Collector Current 1.1A
Current Rating (Max) 1.1A
Dimensions
Height 3.1mm
Length 29mm
Width 12mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
