FSAM30SM60A
RoHS
/
Package 32-PowerDIP Module (1.370, 34.80mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
SMART POWER MODULE 30A SPM32-AA
PDF
/
Buying Options
Total Price: USD $59.65
Unit Price: USD $59.6464
≥1 USD $59.6464
Inventory: 140
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 31mm
Length 60mm
Height 7.2mm
Technical
Min Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.3V
Collector Emitter Breakdown Voltage 600V
Collector Emitter Voltage (VCEO) 2.3V
Output Current 30A
Power Dissipation 62W
Max Current Rating 30A
Configuration 3 Phase
Supply Voltage-Min (Vsup) 13.5V
Supply Voltage-Max (Vsup) 16.5V
Voltage - Isolation 2500Vrms
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 62W
HTS Code 8541.29.00.95
Min Operating Temperature -20°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Type IGBT
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series Motion SPM? 2
Published 2011
Physical
Weight 32.58g
Number of Pins 32
Package / Case 32-PowerDIP Module (1.370, 34.80mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 4 days ago)
