IRAM136-0461G

Infineon Technologies
RoHS
/
Package 23-PowerSSIP Module, 22 Leads, Formed Leads
Category Discrete Semiconductor Products / Power Driver Modules
Description iMOTION? 23-PowerSSIP Module 22Leads Formed Leads Through Hole IGBT Power Driver Module 9.4A 600V 125C
PDF
/
Buying Options
Total Price: USD $14.43
Unit Price: USD $14.425996
≥1 USD $14.425996
≥10 USD $13.609427
≥100 USD $12.839088
≥500 USD $12.112341
≥1000 USD $11.426739
Inventory: 1298
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Current 9.4A
Min Supply Voltage 12V
Max Supply Voltage 20V
Voltage 600V
Configuration 3 Phase
Temperature Grade AUTOMOTIVE
Voltage - Isolation 2000Vrms
Qualification Status Not Qualified
JESD-30 Code R-XZFM-T23
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position ZIG-ZAG
Technology BIPOLAR
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type IGBT
Number of Terminations 23
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series iMOTION?
Published 2006

Physical

Package / Case 23-PowerSSIP Module, 22 Leads, Formed Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 9 Weeks
