MAX607ESA
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
STEP-UP DC-DC CONVERTER
PDF
/
Buying Options
Total Price: USD $7.06
Unit Price: USD $7.0623
≥1 USD $7.0623
≥10 USD $5.795
≥100 USD $5.61355
≥500 USD $5.4321
≥1000 USD $5.2516
Inventory: 1677
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish TIN LEAD
Applications Converter, Flash Memory PCMCIA Cards
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDSO-G8
Number of Outputs 1
Qualification Status COMMERCIAL
Output Voltage 5V
Input Voltage-Nom 3.3V
Analog IC - Other Type SWITCHING REGULATOR
Voltage - Input 3V~5.5V
Voltage - Output 5V 12V 3V~12.5V
Control Mode CURRENT-MODE
Control Technique PULSE FREQUENCY MODULATION
Switcher Configuration BOOST
Switching Frequency-Max 500kHz
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
