TK11250BMCL
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Lead Free GULL WING Not Qualified BIPOLAR voltage regulator linear 150C 0.15A 3.4mm 5.1V
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 18202
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Number of Terminations 6
ECCN Code EAR99
HTS Code 8542.39.00.01
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 0.95mm
JESD-30 Code R-PDSO-G6
Number of Outputs 1
Qualification Status Not Qualified
Operating Temperature (Max) 80°C
Operating Temperature (Min) -30°C
Output Voltage 1 5V
Input Voltage (Min) 6V
Input Voltage (Max) 14.5V
Dropout Voltage1-Nom 0.26V
Output Voltage1-Max 5.1V
Output Voltage1-Min 4.9V
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max 2%
Output Current1-Max 0.15A
Dropout Voltage1-Max 0.39V
Operating Temperature TJ-Max 150°C
Input Voltage Absolute-Max 16V
Adjustability FIXED
Load Regulation-Max(%) 0.09%
Line Regulation-Max (%/V) 0.02%
Dimensions
Height Seated (Max) 1.4mm
Length 3.4mm
Width 2.2mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
