TPS79425DCQR
RoHS
RoHS compliant
RoHS compliantPackage SOT-223-6
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS79425 Cut Tape (CT) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 145mV 1.8mm 250mA -40C~125C
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.2088
≥1 USD $2.2088
≥10 USD $1.98792
≥100 USD $1.875456
≥500 USD $1.597816
≥1000 USD $1.500294
≥3000 USD $1.312749
Inventory: 1651
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.6mm
Width 3.5mm
Length 6.5mm
Height 1.8mm
Technical
Output Voltage Accuracy 3 %
Input Bias Current 170μA
Voltage Tolerance-Max 3%
Min Output Voltage 2.5V
Dropout Voltage1-Nom 0.155V
Dropout Voltage 145mV
PSRR 65dB ~ 40dB (100Hz ~ 100kHz)
Current - Quiescent (Iq) 220μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 2.5V
Max Output Voltage 2.5V
Accuracy 3 %
Control Features Enable
Quiescent Current 260μA
Output Configuration Positive
Max Output Current 250mA
Output Type Fixed
Output Voltage 2.5V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Pin Count 6
Base Part Number TPS79425
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Surface Mount YES
Package / Case SOT-223-6
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Alternative Model
