TPS77215DGK
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~125C 412mW 150mA 3mm
PDF
/
Buying Options
Total Price: USD $1.67
Unit Price: USD $1.6687
≥1 USD $1.6687
≥10 USD $1.574245
≥100 USD $1.485139
≥500 USD $1.401074
≥1000 USD $1.321765
Inventory: 1480
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Max Power Dissipation 412mW
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPS77215
Pin Count 8
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 1.5V
Output Type Fixed
Max Output Current 150mA
Output Configuration Positive
Power Dissipation 412mW
Quiescent Current 90μA
Control Features Enable, Power Good
Accuracy 2 %
Max Output Voltage 1.5V
Output Voltage 1 1.5V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 125μA
PSRR 60dB (1kHz)
Dropout Voltage 75mV
Min Output Voltage 1.5V
Voltage Tolerance-Max 2%
Input Bias Current 92μA
Output Voltage Accuracy 2 %
Dimensions
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
