LP3966ES-5.0/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP3966 Tube Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 800mV 4.8mm 3A -40C~125C
PDF
/
Inventory: 7557
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8.635mm
Height Seated (Max) 4.8mm
Technical
Min Current Limit 4A
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.8V
Dropout Voltage 800mV
Voltage Dropout (Max) 1.2V @ 3A
Current - Quiescent (Iq) 9mA
Protection Features Over Current, Over Temperature, Short Circuit
Number of Regulators 1
Input Voltage (Min) 6.2V
Output Voltage 1 5V
Control Features Enable
Current - Output 3A
Output Configuration Positive
Output Type Fixed
Output Voltage 5V
Voltage - Input (Max) 7V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 15mA
JESD-30 Code R-PSSO-G5
Base Part Number LP3966
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Technology CMOS
Packing Method RAIL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Mounting Type Surface Mount
Mount Surface Mount
