LP3892EMR-1.2
RoHS
/
Package 8-PowerSOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Contains Lead Positive GULL WING voltage regulator linear -40C~125C 1.5A 1.47mm 140mV
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1342
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-PowerSOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Packing Method RAIL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number LP3892
Pin Count 8
Current - Supply (Max) 8mA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 1.2V
Output Type Fixed
Max Output Current 1.5A
Output Configuration Positive
Quiescent Current 4mA
Control Features Enable
Accuracy 1.5 %
Output Voltage 1 1.2V
Number of Regulators 1
Min Input Voltage 1.34V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 30μA
Voltage Dropout (Max) 0.55V @ 1.5A
PSRR 80dB ~ 65dB (120Hz ~ 1kHz)
Dropout Voltage 140mV
Dropout Voltage1-Nom 0.155V
Voltage Tolerance-Max 2.5%
Input Voltage Absolute-Max 6V
Output Voltage Accuracy 1.5 %
Dimensions
Height 1.47mm
Length 4.93mm
Width 3.94mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
