LP2986IM-3.3
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP2986 Tube Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 0.35V 4.9mm 200mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
Inventory: 328
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.35V
PSRR 65dB (1kHz)
Voltage Dropout (Max) 0.35V @ 200mA
Current - Quiescent (Iq) 120μA
Protection Features Over Current, Over Temperature, Short Circuit
Number of Regulators 1
Voltage - Output (Min/Fixed) 3.3V
Output Voltage 1 3.3V
Control Features Enable
Current - Output 200mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 16V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 3.7mA
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number LP2986
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method RAIL
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Alternative Model
