LP2953IM
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Not For New Designs Contains Lead Positive GULL WING Linear Voltage Regulator IC -40C~125C 250mA 9.9mm 470mV
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.7512
≥1 USD $1.7512
Inventory: 2514
Minimum: 1
-
+
Technical Details
Technical
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 235
Number of Functions 1
Base Part Number LP2953
Pin Count 16
Current - Supply (Max) 33mA
Number of Outputs 1
Voltage - Input (Max) 30V
Output Voltage 29V
Output Type Adjustable (Fixed)
Max Output Current 250mA
Output Configuration Positive
Quiescent Current 170μA
Control Features Enable
Output Voltage 1 5V
Voltage - Output (Min/Fixed) 1.23V 5V
Number of Regulators 1
Min Input Voltage -20V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 170μA
Voltage Dropout (Max) 0.8V @ 250mA
Reference Voltage 1.255V
Dropout Voltage 470mV
Dropout Voltage1-Nom 0.8V
Voltage Tolerance-Max 2.4%
Input Voltage Absolute-Max 30V
Load Regulation-Max(%) 0.3%
Subcategory Other Regulators
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
