LP2953AMGW-QMLV
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead GULL WING Not Qualified 38535Q/M;38534H;883B voltage regulator linear 150C 1A 2.34mm 29V
PDF
/
Inventory: 7771
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Thickness 1.778mm
Width 6.35mm
Length 9.906mm
Height 2.34mm
Technical
Line Regulation-Max (%/V) 0.0083
Load Regulation-Max(%) 0.2%
Adjustability FIXED
Input Voltage Absolute-Max 30V
Operating Temperature TJ-Max 150°C
Screening Level 38535Q/M;38534H;883B
Voltage Tolerance-Max 1.4%
Regulator Type FIXED/ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Voltage1-Min 1.23V
Output Voltage1-Max 29V
Dropout Voltage1-Nom 0.47V
Dropout Voltage 470mV
Input Voltage (Max) 30V
Input Voltage (Min) 20V
Output Voltage 1 5V
Quiescent Current 130μA
Current - Output 1A
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Other Regulators
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
Physical
Number of Pins 16
Surface Mount YES
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
