LMS5214IMGX-3.3/NOPB

Texas Instruments
RoHS
RoHS RoHS compliant
Package 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Obsolete Positive GULL WING CMOS voltage regulator linear -40C~125C 209mW 80mA 2mm
PDF
/
Inventory: 8560
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-TSSOP, SC-70-5, SOT-353
Number of Pins 5

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Max Power Dissipation 209mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number LMS5214
Pin Count 5
Current - Supply (Max) 10μA
Number of Outputs 1
Voltage - Input (Max) 6V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 80mA
Output Configuration Positive
Control Features Enable
Accuracy 3 %
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 1μA
Voltage Dropout (Max) 0.20V @ 100μA
Reference Voltage 1.25V
Dropout Voltage 300mV
Dropout Voltage1-Nom 0.3V
Voltage Tolerance-Max 4%

Dimensions

Length 2mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
