LM2940SX-12/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Contains Lead Positive GULL WING Linear Voltage Regulator IC -40C~125C 1A 4.83mm 500mV
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.716
≥1 USD $1.716
≥10 USD $1.53824
≥100 USD $1.450944
≥500 USD $1.236224
≥1000 USD $1.160755
Inventory: 663
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 4.44mm
Width 8.41mm
Length 10.18mm
Height 4.83mm
Technical
Input Voltage Absolute-Max 60V
Voltage Tolerance-Max 5%
Dropout Voltage1-Nom 0.5V
Dropout Voltage 500mV
PSRR 66dB (120Hz)
Voltage Dropout (Max) 1V @ 1A
Current - Quiescent (Iq) 10mA
Protection Features Over Current, Over Temperature, Reverse Polarity, Short Circuit
Min Input Voltage 13.6V
Number of Regulators 1
Output Voltage 1 12V
Quiescent Current 15mA
Output Configuration Positive
Max Output Current 1A
Output Type Fixed
Output Voltage 12V
Voltage - Input (Max) 26V
Number of Outputs 1
Current - Supply (Max) 15mA
Pin Count 4
Base Part Number LM2940
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
