XRP7724ILB-F
RoHS
RoHS compliant
RoHS compliantPackage 44-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear + Switching
Description
IC REG 6OUT BUCK/LINEAR 44TQFN
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.73975
≥1 USD $10.73975
≥10 USD $8.8122
≥100 USD $8.5367
≥500 USD $8.2612
≥1000 USD $7.9857
Inventory: 19
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 0.8mm
Technical
w/Supervisor No
Voltage/Current - Output 3 Controller
w/Sequencer Yes
Frequency - Switching 105kHz~1.23MHz
Topology Step-Down (Buck) (4), Linear (LDO) (2)
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 4
Supply Voltage-Min (Vsup) 5.5V
Supply Voltage-Max (Vsup) 25V
Number of Outputs 6
JESD-30 Code S-XQCC-N44
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 4.75V~25V
HTS Code 8542.39.00.01
Additional Feature ALSO OPERATES IN SUPPLY VOLTAGE RANGE 4.75 TO 5.5 VOLT
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 44-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
