LM350K
RoHS
RoHS compliant
RoHS compliantPackage TO-204AA, TO-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LM350 Tube Through Hole Over Current Over Temperature voltage regulator linear 4.2V 6.40101g 3A 30W
PDF
/
Buying Options
Total Price: USD $77.1
Unit Price: USD $77.102
≥1 USD $77.102
≥10 USD $74.6928
≥100 USD $72.28265
≥500 USD $69.87345
≥1000 USD $62.6449
Inventory: 255
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-204AA, TO-3
Weight 6.40101g
Technical
Operating Temperature 0°C~125°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Regulators
Max Power Dissipation 30W
Technology BIPOLAR
Terminal Position BOTTOM
Terminal Form PIN/PEG
Number of Functions 1
Base Part Number LM350
Pin Count 2
JESD-30 Code O-MBFM-P2
Number of Outputs 1
Voltage - Input (Max) 35V
Output Voltage 25V
Output Type Adjustable
Max Output Current 3A
Output Configuration Positive
Power Dissipation 30W
Voltage - Output (Min/Fixed) 1.2V
Number of Regulators 1
Min Input Voltage 4.2V
Protection Features Over Current, Over Temperature
PSRR 86dB ~ 65dB (120Hz)
Reference Voltage 1.29V
Power Supply Rejection Ratio (PSRR) 86dB
Min Current Limit 3A
Load Regulation-Max(%) 0.5%
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
